EDC-Series – High Efficiency Double Conversion UPS with Power Conditioner

  • Integrated Power Conditioner

  • Extended Battery Module Capability

  • Built-in Power Factor Correction

  • Pure Sine Wave Output with 0.9 Power Factor

  • Adjustable LED Display

  • Rack or Tower Configuration

  • Real-time Voltage & Frequency Regulation – Generator Compatible

Advanced Overload Protection

  • Multiple overload level detection allows for extended time of uninterrupted operation during various stages of overloading.
  • Automatic switching to BYPASS mode for additional time of uninterrupted operation.

Designed For:

  • Critical server

  • Network

  • AV Systems

  • Telecommunications equipment

Real-time Network Monitoring and Notifications

  • Remote management and configuration via Web Browser, NMS
  • Event logging to trace the operation’s history
  • Graphic data logging to analyze power conditions
  • Event notifications via Email, SNMP traps
  • It has the ability to set up for an alert when the battery is in need of replacement
  • Supports Environmental Sensor (optional) advanced Enterprise power management software
  • Power ON/OFF, reboot, and on demand battery testing for UPS.

  LCD Display

  • Easy-to-read LCD display provides information about power conditions
  • The LCD display will show how much time is left before the UPS will turn back on or shut down
  • Unit can be controlled via LCD display and via network card web console.
    LCD can be easily rotated via software.
  • Displays various information in detail, such as load levels in VA or WATT, backup time at current load, battery pack voltage, etc.

OTHER FEATURES

  • Integrated Power Conditioner for Protection against Common Mode, Normal Mode, Ground Loop Interferences
  • High efficiency On-Line double Conversion / pure sine wave output design
  • Fully informative LCD display to show power loads and UPS stats
  • Automatic voltage regulator (AVR and battery backup in one unit)
  • Short circuit and overload protection with automatic bypass capability
  • Power management software with network monitoring capability with diagnostic and battery check
  • Gigabit Network surge protection circuit
  • HID USB and Smart RS232 communications port
  • User replaceable UPS battery
  • UPS can power on with or no batteries
  • SNMP network management capability
  • EPO (Emergency Power Off) capable
  • Two year warranty – Optional extended warranty

PROTECTION AGAINST...

DOWNLOAD DATASHEET

SPECIFICATIONS

MODEL

EDC1500RT-T

EDC2200RT-T / EDC2200RT-THW

Capacity (VA / Watts)

1500VA / 1350W

2200VA / 1980W

Energy-Saving Technology

Yes, ECO Mode Efficiency ±95%

  INPUT

Input Voltage Range

55~150Vac

Input Frequency Range

50 / 60Hz

Input Power Factor

0.99

Cold Start

Yes

UPS Inlets

IEC C14

IEC C20 / Hardwire Wire Terminal

  OUTPUT

Output Waveform

Pure Sine Wave

Output Voltage

100, 110, 115, 120, 127Vac ±1%*

Output Frequency

50 / 60Hz (Auto Sensing or Configurable) ±0.5Hz**

Line Mode Voltage Regulation

±1%

ECO Mode Voltage Regulation

±10%, ±15% (Configurable)

Crest Factor

3:1

Harmonic Distortion

THD < 3% at Linear Load, THD <6% at Non-Linear Load

UPS Outlets

(8) NEMA 5-15R

(8) NEMA 5-20R ( (4) Remote Switchable Set) /
Terminal+2 NEMA 5-20R

Transfer Time (Typically)

0ms

  BATTERY

Model – Voltage

EP015 – 36VDC (Sealed, Maintenance-Free

EP022 – 48VDC (Sealed, Maintenance-Free)

Run Time (Half Load)

12 Minutes

  PROTECTION

Power Protection

Power Conditioning Protection Against Common Mode, Normal Mode, Ground Loop Interferences

Overload Protection

Line Mode

Battery Mode

Bypass Mode

105%~110% Warning, transfer to bypass after 10min; 110%~130% Warning,
transfer to bypass after 1min; >130% Warning, transfer to bypass after 3s.

105%~110% Warning, shut down after 6min; 110%~130% Warning,
shut down after 1min; >130% Warning, shut down after 3s.

110%~120% Warning, shut down after 30min; 120%~130% Warning,
shut down after 10min; >130% Warning, shut down after 1min.

Short Circuit Protection

UPS Output Cut off Immediately or Input Fuse / Circuit Breaker Protection

  MANAGEMENT

LCD Screen

Graphic LCD

Connectivity Ports

(1) Serial Port (RS232), (1) USB Port

Emergency Power OFF (EPO)

Yes

Audible Alarms

Battery Mode, Battery Low, Overload, UPS Fault, Replace Battery, Bypass Mode,
Charger Failure / Over Charged, Fan Failure, EPO Active

Power Management Software

PowerMaster

SNMP / HTTP Capable

(1) Expansion Port (with optional card)

  ENVIRONMENT

Operating Temperature

0C to 40C

Operating Relative Humidity

20% to 90% Non-Condensing

PHYSICAL

Dimensions (W x D x H) (in)

17.24 x 16.93 x 3.46

Net Weight (Lbs.)

15.40

44.85

Altitude

<2000m

Specifications are subject to change without notice.

(*) Within 50/60Hz±8% by default, the output frequency is synchronization with input mains. User can adjust the acceptable range for output frequency (±1, 2, 3, 4, 5, 6, 7, 8, 9, 10%). When input frequency is out of synchronization window but within 40-70Hz, UPS can stay in line mode and output frequency is regulated at 50/60Hz+0.5% with load derating by 40%.

software included

Power Master+ management software provides a user-friendly interface for your power systems. The graphic user-interface is intuitive and displays essential power information at a glance. Download here.

TROUBLESHOOTING

Problem: O/P Overload
Possible Cause: Your equipment requires more power than the UPS can provide. If the UPS is in Line Mode then it will transfer to Bypass Mode; if the UPS is in Battery Mode it will shut down.
Solution: Shut off non–essential equipment. If this solves the overload problem, the UPS will transfer to normal operation.

Problem: Battery Mode
Possible Cause: UPS is operating on battery power.
Solution: Save your data and perform a controlled-shutdown.

Problem: Battery Low
Possible Cause: UPS is operating on battery power and will be shutting down soon due to extremely low battery voltage.
Solution: UPS will restart automatically when acceptable utility power returns.

Problem: BAT Disconnected / Battery Replace.
Possible Cause: Missing battery power.
Solution: Check battery connector when use battery packages.
Possible Cause 2: UPS has failed in Battery Test.
Solution 2: Contact technical support to replace the battery.

Problem: Charger Failure.
Possible Cause: Charger has failed.
Solution: 1. Shut down UPS and turn off AC input. 2. Contact Supplier for repair.

Problem: EPO OFF,
Possible Cause: Missing the EPO connection.
Solution: Check the EPO connection.

Problem: Over Temperature
Possible Cause: High ambient temperature.
Solution: 1. Shut down UPS. Restart UPS to Check the fan for operation and if the ventilation hole has been covered. 2.Contact supplies for repair.

Problem: Output Short.
Possible Cause: Output short circuit.
Solution: 1. Shut down UPS. 2. Your attached equipment may have problems, please remove them and check again.

Problem: High O/P V.
Possible Cause: Output voltage is too high.
Solution: 1. Shut down UPS. 2.Contact supplies for repair.

Problem: Low O/P V.
Possible Cause: Output voltage is too low.
Solution: 1. Shut down UPS. 2.Contact supplies for repair.

Problem: Bus Fault
Possible Cause: Internal DC bus voltage is too high or too low.
Solution: 1. Shut down UPS. 2.Contact supplies for repair.

Problem: Startup fail.
Possible Cause: High temperature , or fan fail, or battery low, or EPO off.
Solution: 1. Restart UPS and press the “DOWN” button to view the warning event. Then refer to the solution for the warning. 2.Contact supplies for repair.
